Commercial Lighting>WX Venture Lamp Series

Product Model:CL-SPLWXA

Product Size:

90 Single-Head:152*152*105mm;

90 Double-Head:280*152*150mm;

90 Triple-Head:405*152*150mm;

111 Single-Head:180*180*130mm;

111 Double-Head:325*180*170mm;

111 Triple-Head:475*180*170mm;

CCT: 3000K/4000K/5000K;

Luminous Efficacy: 80LM/W;

Lighting Source: 1205C;

Beamgle Angle:15°/25°/36°

CRI: 80

Working Environment Temperature:-40℃~55℃;

Storage Environment Temperature:-20℃~65℃;

IP Grade:IP20;

Service Life:>30000hours;

Material:   Cold stamping aluminum alloy housing shell+Central matte glass





Download product series manual
  • Product Characteristic
  • Product Application

Lifetime with 8 times longer than CFL.
360 degree viewing angle.
Used high quality imported LED chips.
Scientific and effective driver configuration, no strobe.
1. Lamp housing with high quality aluminum, and thermal performance.
2. Low-power and high-efficiency imported chips, high lumen, CRI, and long lifetime.
3.Rational structure optimization, multi-angle rotating design, using trunk light inside, extension and ratating angle, totally meeting multi-angle needs.
4 Safety and reliability, and safe to touch, and be able to precisely control the light type and viewing angle with soft  light and glare-free.
5 Free from health harmful substance as Hg and Na, etc.

Used in indoor lighting as mall, office, hotel, bar, exhibition hall, etc.
